The SUB 705-AS II is a compact and powerful bass reflex subwoofer. It is equipped with a 15” high power woofer with 3” voice coil, powered by a 1400 Watt digital amplifier in a robust plywood housing with deep and punchy tuning for a powerful bass. Thanks to the built-in digital stereo crossover (DSP) with adjustable crossover frequency, it can be easily and quickly set up with a satellite speaker. The SUB 705-AS II easily combines with 12” and 15”, ideal for RCF ART and D-Line Series.

1400 Watt Digital Amplifier
15″ Woofer, bass reflex housing
Stereo crossover
Switchable crossover frequencies
Phase-reverse switch
Electronic equalization, soft limiter and protection
Stereo XLR input, Stereo XLR signal output

SPECIFICATIONS:

ACOUSTICAL SPECIFICATIONS
Frequency Response -3 dB: 40 Hz ÷ 120 Hz
Max SPL: 131 dB
Woofer: 15″, 3.0″ v.c.

INPUT/OUTPUT SECTION
Input connectors: Stereo XLR
Output connectors: Stereo XLR
Input sensitivity: -2 dBu / + 4 dBu

PROCESSOR SECTION
Crossover frequencies: 80-110 Hz Hz
Protections: thermal, rms
Limiter: soft limiter
Controls: Volume, EQ, phase, xover

AMPLIFIER SPECIFICATIONS
Total power: 1400 W PEAK
Low frequencies: 1400 W PEAK
Total power: 700 W RMS
Low frequencies: 700 W RMS
Cooling: convection
Connections: VDE connector

CABINET
Cabinet Material: Baltic birch plywood
Hardware: Pole mount
Handles: 2 side
Pole Mount/Cap: yes
Grille: Steel
Colour: Black

Physical & Dimensions
Height: 568mm
Width: 430mm
Depth: 595mm
Weight: 28kg
